医用内窥镜系统的组成

来源:http://www.jiangrenyiliao.cn/ 发布时间:2023-05-20 浏览量:0

医用内窥镜系统主要由设备系统与手术器械系统组成。手术器械系统主要按科室或手术名称来分类。有各科使用的内窥镜、专用器械、配合设备使用的手术器械和一次性手术耗材。这里就不详细介绍了,下面内窥镜维修公司来讲一下设备系统的结构组成。
The medical endoscope system mainly consists of equipment system and surgical instrument system. The surgical instrument system is mainly classified by department or surgical name. There are endoscopes, specialized instruments, surgical instruments used in conjunction with equipment, and disposable surgical consumables used in various departments. I won't go into detail here. Below, the endoscope maintenance company will explain the structural composition of the equipment system.
在设备系统中我们通常可以分为:摄像显像系统,影像记录系统,光源系统,人工气腹系统,液体加压系统,电凝电切系统,动力消融系统,冲洗吸引系统等等。
In equipment systems, we can usually be divided into: camera imaging systems, image recording systems, light source systems, artificial pneumoperitoneum systems, liquid pressurization systems, electrocoagulation and electrocautery systems, dynamic ablation systems, flushing and suction systems, and so on.
(1)摄像显像系统:该系统包括显示器和摄像机。显示器有常规的CRT和液晶两种,摄像机有单CCD和3CCD两种。现在高端的使用客户多是液晶显示器配3CCD摄像器。
(1) Camera and imaging system: This system includes a display and a camera. There are two types of monitors: conventional CRT and LCD, and two types of cameras: single CCD and 3CCD. Nowadays, high-end customers mostly use LCD monitors with 3CCD cameras.
(2)影像记录系统:现在很多医院都选择以电脑为基础的图文工作站。该系统分两部分:电脑硬件和图文采集软件。
(2) Image recording system: Nowadays, many hospitals choose computer-based image and text workstations. The system is divided into two parts: computer hardware and image and text acquisition software.
内窥镜维修公司
(3)源系统:又称冷光源。冷光源灯泡中充有卤素和氙气两种,其输出功率为70-400W。现在300W氙光源是主流的产品。其突出特点是光线强烈,色温5600-6000k,与太阳光类似,涵盖了从紫外线到红外线的整个波段。
(3) Source system: also known as cold light source. The cold light bulb is filled with halogen and xenon gas, with an output power of 70-400W. The 300W xenon light source is now the mainstream product. Its prominent feature is strong light, with a color temperature of 5600-6000k, similar to sunlight, covering the entire spectrum from ultraviolet to infrared.
(4)人工气腹系统:将气腹机与二氧化碳钢瓶连接好,并旋开钢瓶上的阀门,然后开启气腹机,根据手术的需要,选择压力预设值,当腹腔内压力超过或低于设定值时,全自动二氧化碳气腹机可自动开始或停止注气。
(4) Artificial pneumoperitoneum system: Connect the pneumoperitoneum machine to a carbon dioxide cylinder, unscrew the valve on the cylinder, and then turn on the pneumoperitoneum machine. According to the surgical needs, select a preset pressure value. When the abdominal pressure exceeds or falls below the set value, the fully automatic carbon dioxide pneumoperitoneum machine can automatically start or stop gas injection.
医用内窥镜系统的组成事项就讲解到这里了,希望能够给您好的帮助,更多事项就来我们网站http://www.jiangrenyiliao.cn咨询!
That's all for the composition of the medical endoscope system. We hope it can be helpful to you. For more information, please come to our website http://www.jiangrenyiliao.cn consulting service
